The FusionServer 2288H V6 is a 2U 2-socket rack server with flexible configurations, widely utilized for cloud computing, virtualization, database, and big data workloads. Designed for versatility, the 2288H V6 supports 2-socket Intel® Xeon® Scalable processors, up to 32 DDR4 RAM modules, and 14 PCIe expansion slots, providing extensive local storage resources.
It integrates advanced patented technologies including DEMT (Dynamic Energy Management Technology), intelligent power management, and FDM (Fault Diagnosis & Management) for proactive fault handling, significantly reducing operational costs and improving ROI.
| Server Model | FusionServer 2288H V6 |
| Form Factor | 2U rack server |
| Processors | One or two 3rd Gen Intel® Xeon® Scalable Ice Lake processors (8300/6300/5300/4300 series), TDP up to 270 W |
| Local Storage |
• 8-31 x 2.5-inch SAS/SATA/SSD drives • 12-20 x 3.5-inch SAS/SATA drives • 4/8/16/24 NVMe SSDs • Supports Dual M.2 SSDs |
| RAID Support | RAID 0, 1, 10, 1E, 5, 50, 6, or 60; optional supercapacitor for cache protection; remote web-based configuration. |
| Network | OCP 3.0 NICs supported; Two FlexIO card slots for network adapters; Hot swappable function supported. |
| PCIe Expansion | Maximum of 14 PCIe 4.0 slots (including dedicated slots for RAID and OCP 3.0). |
| Chip Set | Intel C621A |
| Management | iBMC chip integrates GE management port; supports Redfish, SNMP, IPMI 2.0, HTML5/VNC KVM; Optional FusionDirector software. |
| Operating Systems | Windows Server, SUSE Linux Enterprise, VMware ESXi, Red Hat Enterprise, CentOS, Oracle, Ubuntu, Debian. |
| Fan Modules | Four hot-swappable counter-rotating fan modules in N+1 redundancy mode. |
| Dimensions | 86.1 mm x 447 mm x 790 mm (3.39 in. x 17.60 in. x 31.10 in.) |
| Power Supply | Dual hot-swappable PSUs (1+1 redundancy); Options range from 900W to 3000W (Platinum/Titanium/HVDC). |
