FusionServer 2288H V6 2U rack server
The FusionServer 2288H V6 is a 2U 2-socket rack server with flexible configurations, which can be widely used for cloud computing, virtualization, database, and big data workloads. The 2288H V6 can be configured with 2-socket Intel® Xeon® Scalable processors, 32 DDR4 RAM, 14 PCIe expansion slots, and supports large local storage resources.
It integrates patented technologies such as DEMT, intelligent power consumption management, FDM intelligent fault management, and optional FusionDirector full lifecycle management software, which can effectively reduce operations cost and improve return on investment.
| Server Model | FusionServer 2288H V6 |
| Form Factor | 2U rack server |
| Processors | One or two 3rd Gen Intel® Xeon® Scalable Ice Lake processors (8300/6300/5300/4300 series), TDP up to 270 W |
| Local Storage |
• 8-31 x 2.5-inch SAS/SATA/SSD drives • 12-20 x 3.5-inch SAS/SATA drives • 4/8/16/24 NVMe SSDs • Dual M.2 SSDs supported |
| RAID Support | Supports RAID 0, 1, 10, 1E, 5, 50, 6, or 60, optional supercapacitor for cache data power failure protection. |
| Network | Provides OCP 3.0 NICs. Two FlexIO card slots support two OCP 3.0 network adapters. |
| PCIe Expansion | Maximum of 14 PCIe 4.0 slots, including one dedicated for RAID and two for OCP 3.0. |
| Chip Set | Intel C621A |
| Management | iBMC chip integrates one GE management port; supports Redfish, SNMP, IPMI 2.0, HTML5/VNC KVM; optional FusionDirector software. |
| Operating Systems | Windows Server, SUSE Linux, VMware ESXi, Red Hat, CentOS, Oracle, Ubuntu, Debian, etc. |
| Power Supply | Two hot-swappable PSUs (1+1 redundancy); Options: 900W, 1200W, 1500W, 2000W, 3000W. |
| Dimensions | 86.1 mm x 447 mm x 790 mm |
As a leading integrated IT solutions provider, we combine cutting-edge manufacturing, dedicated R&D facilities, and a robust global distribution network to deliver comprehensive end-to-end infrastructure services. Our team of over 300 professionals includes more than 150 certified engineers with top-tier certifications.
We bring 15 years of proven expertise in designing, deploying, and maintaining mission-critical IT environments for enterprises worldwide. As authorized partners for major brands like xFusion, Dell, HPE, and Lenovo, we provide computing servers, network storage, switches, and high-performance accessories.
To better ensure the safety of your goods, professional, environmentally friendly, convenient and efficient packaging services will be provided. All hardware is secured in industry-standard protective materials to prevent damage during transit.
